M17/195-00001 | Flexible Coaxial Cable, 93 Ohms
Characteristics:
- Copper-covered steel conductor
- Polyethylene (PE) insulation, 0.146"
- Two bare copper braid shields
- Cross-linked Polyolefin (XLPE) jacket
- Temperature range: -20°C to +80°C
Applications:
- General low-temperature applications
Comments:
- Low-smoke, halogen-free (LSZH) M17/90-RG71
Conductor Stranding: Solid
Nom. Dia. of Conductor (in): 0.0253
Nom. O.D. (in): 0.245
Weight (lb/ft): 0.053
Nom. Imp. ohms Vp (%): 93
Nom. Cap. pF/ft: 13.5
Max Volts vrms: 750
